    Contents Items SC5021XXYWQ6B4
    （Cargo van-Standard）    		 SC5021XXYWQ6B4
    （Cargo van-Confortable）    		 SC5021XXYWQ6B4
    （Cargo van-Luxuary）    		 SC5021XXYWQ6B4
    （Cargo van-Premium）
    Vehicle Dimension Length(mm) 4200 4200 4200 4200
    Width(mm) 1680 1680 1680 1680
    Height(mm) 1965 1965 1965 1965
    Wheel base（mm） 2700 2700 2700 2700
    Wheel Tread Front wheel（mm） 1450 1450 1450 1450
    Rear wheel（mm） 1455 1455 1455 1455
    Mass Parameter(kg) Gross vehicles weight(kg) 2190 2190 2190 2190
    Curb weight(kg) 1215 1215 1215 1215
    Max. payload(kg) 650 650 650 650
    Seating capacity（person） 2+3 2+3 2+3 2+3
    Engine Model JL473QH（VI B） JL473QH（VI B） JL473QH（VI B） JL473QH（VI B）
    Fuel category Gasoline Gasoline Gasoline Gasoline
    Rated power (KW) 78.5 78.5 78.5 78.5
    Maximum net power (KW) 74.5 74.5 74.5 74.5
    Displacement(ml) 1480 1480 1480 1480
    MaximumTorque（N.m） 141 141 141 141
    Main performance parameter Maximum speed(km/h) 120 120 120 120
    Maximum climbing ability (％) 30 30 30 30
    Minimum turning circles diameter (m) 11.6 11.6 11.6 11.6
    Minimum ground clearance (mm) 172 172 172 172
    Tyre 175/70R14LT 8PR 175/70R14LT 8PR 175/70R14LT 8PR 175/70R14LT 8PR
    General Configurations Front Suspension Independent Independent Independent Independent
    ABS ● ● ● ●
    EPS – – ● ●
    Heater ● ● ● ●
    Front Fog Lamp – ● ● ●
    Dual Speaker ● ● – –
    Four Speakers – – ● ●
    Inner Boarding Step – ● ● ●
    Headlamp Height Adjustable ● ● ● ●
    Front Roof Lamp – ● ● ●
    Middle Roof Lamp – – ● ●
    Radio ● ● ● –
    USB Cable – ● ● –
    MP5 – – – ●
    Sunvior Single Single Dual Dual
    Reverse-View Camera – – – ●
    Power Window – – ● ●
    A/C (Single Area) Optional Optional Optional Optional
    Central Lock – – ● ●
